Filabot Former - Injection Molding for 3D Printing

Recycle polymers, develop new parts, and research like never before. The Filabot Former is a simplified injection molder that is designed to work with the Filabot product line and provide additional material processing options to our development systems.  Filabot Former comes with a 1 Year Limited Warranty.

Includes:

• Filabot Former Machine

• Practice Mold
• Purge Block
• Pour Tube
• Handle Extension
• Sprue Cutter Pliers
• Needle Nose Pliers
• Wooden Craft Sticks
• Mold Release Spray
• 1 lb. of Pellets (LDPE)

Specifications:

• Maximum processing temperature 600F (316C)
• Injection tube capacity Volume = 1 cu. inch. (16cc) – (about 17g of PS by weight)
• Volts AC / Hz 120V or 240V   50/60Hz (see label on machine and controller)
• Watts 400
• Power switch (w/ built in thermal breaker) 5 AMP
• Maximum mold size 2.50”W x 2.63”H x 4.00”L (≈ 67mm X 64mm x 102mm)
• Injection nozzle orifice .125” dia. (≈ 3.17mm)
• Sprue center line 1.25” (32mm)  distance from backing plate to nozzle orifice center
• Machine weight 35 lbs. (≈16Kg)
• Machine footprint 4.00”W x 8.25”D  (≈10cm x 21cm)
• Maximum machine dimension 9” x 14” x 25” (w/ handle up)   (≈ 23cm x 36cm x 64cm)
